Understanding VESA Standards
The Video Electronics Standards Association (VESA) is the organization responsible for defining the standards involved with mounting computer monitors, TVs, and other flat panel displays using wall mounts or stands. The vesa mounting standards make it easier for manufacturers to deliver on consumers’ needs, allowing for general interchangeability between monitor mounts and brackets, regardless of the monitor’s brand. These standards also allow for the affordable installation of mounts and stands for improved ergonomics and flexibility.
TVs and displays that are VESA compatible feature four holes on their backs. This pattern is measured horizontally and vertically usually with the mounting holes drilled directly into the steel frame of the monitor.
VESA monitor mount standards determine:
- The hole pattern at the back of the monitor
- The size of the screws necessary to attach the mount to the monitor
- The weight capacity that the mount will support
These are mainly determined by the screen size and dimensions of the monitor you plan to mount.
Can All Monitors Be Mounted?
The short answer is: Yes. The majority of current monitor models are VESA compliant and allow for easy mounting on the wall or a desk mount. Some brands sell monitors without the standard VESA pattern on the back. These can still be mounted using a VESA mount but need an adapter to make them compatible with VESA mounting solutions.
Is Your Computer Monitor VESA Compliant?
Most modern flat-panel monitors and TVs are designed with VESA compliance in mind. To determine if your computer monitor complies with VESA standards, simply check the back. If it does comply, you should see the standard four-hole screw pattern in the back of your monitor. The most common pattern for the screw holes is either 75 x 75 mm or 100 x 100 mm, while larger monitors will be 200 x 100 mm.
Some monitors, particularly those that include their own stands or mounts, will have these holes hidden. Remove the attached mount or rear panel as instructed in the user manual. You can also refer to your monitor’s user guide, which should usually provide information on VESA compatibility.
If you are truly not sure if your monitor can be mounted, check online or reach out to the manufacturer directly to find out if your monitor is VESA compliant.
How To Mount a Monitor Without VESA?
Apple’s monitors are known to not be VESA compatible. Smaller, cheaper monitors, monitors that are curved, and monitors that are too thin usually have a hole pattern that is not compatible with VESA mounts. That means you will have to use the custom stands and mounts provided directly by the first-party manufacturer.
The good news: if you still want to use a VESA mountable monitor, adapters for these mounts are readily available and generally easy to use. Some adapters, like those provided for Apple computers, act as an aftermarket VESA plate and screw onto the back of the monitor, allowing you to then attach a mount or monitor stand as usual. Other adapters essentially clamp onto your monitor so that you can avoid screwing anything directly into your monitor.
Choosing the Right Mount
Whether your display is compatible or requires an adapter, make sure you follow through by choosing the right mount for your needs. Pay attention to the screen size and weight ratings for your selected mount to avoid potential damage to your monitor.
It’s good to understand the different types of mounts available along with specifications. Freestanding mounts are the most affordable option, allowing you to change your screen’s height, angle, and rotation without needing to worry about clamps or drilling holes in your desk. However, freestanding mounts don’t feature adjustable arms, making for less customization and fewer adjustments.
Clamp stands are the most common, allowing you to get a full range of motion to adjust viewing angles on the fly. These secure to your desk via a clamp and usually feature an adaptable bracket if you want to drill into your desk or otherwise have a hole in your desk to secure the mount. For more help on mounting your monitor, check out our step-by-step guide on how to mount a monitor.
Monitor mounting is one of the best ways to save space and support ergonomic benefits while you’re working at your computer. As you start browsing for a mount, whether you have a single monitor or multiple monitors, make sure your screen is mountable in the first place or invest in an adapter for surefire mounting.
Are Monitor Mounts Worth It?
In today's office environments, health and productivity play an increasingly important role. One aspect of an ergonomic office workstation is the positioning of your monitor at the correct height and angle. Most monitors are not height adjustable, which is when a monitor mount can help you design a workspace that is perfect for you. Over the years, it has become more popular to work with two or more screens to increase productivity and efficiency. To be able to perfectly align your multiple screens, use a monitor mount that enables you to tilt, swivel and adjust to the perfect position.
