How to Install a TV mount on a Concrete Wall

How to Install a TV mount on a Concrete Wall

To help you install a TV mount on concrete, we have put together the following step-by-step instructions. Installing on a concrete wall is not much different from installing on wooden studs and just as easy if you have the right tools and hardware. Our step-by-step instructions will guide you through the process.

Get your tools and materials ready

First of all, gather the necessary tools and materials to have them handy during the installation process:

  • TV mount kit (including wall plate, brackets, and hardware)
  • Pencil or marker
  • Electric drill
  • Masonry drill bit (suitable for concrete)
  • Safety goggles
  • Hammer
  • Screwdriver
  • Level
  • Anchors (if not provided with the mount kit)
  • Concrete screws or bolts (if not provided with the mount kit)

Step-by-step instructions for the TV installation on a concrete wall

Next, choose the mounting location. Determine where you want to mount your TV and ensure it's at a suitable height and offers a comfortable viewing angle. Also, check for any obstructions or electrical outlets. Now, start with the installation:

  1. Mark the mounting holes: Hold the wall plate against the wall at the desired location. Use a level to ensure it's straight. Mark the center points of the mounting holes on the concrete using a pencil or marker.
  2. Drill pilot holes: Put on safety goggles and insert a masonry drill bit into the electric drill. Drill pilot holes at the marked center points on the concrete wall. Use a drill bit that matches the size of the anchors you'll be using.
  3. Insert anchors: If your TV mount kit includes anchors, insert them into the pilot holes. Tap them gently with a hammer until they're flush with the wall surface.
  4. Attach the wall plate: Position the wall plate over the pilot holes, aligning them with the anchors. Use a screwdriver or drill to secure the wall plate to the anchors. Make sure the wall plate is securely attached to the concrete wall.
  5. Attach brackets to the TV: Depending on the type of TV mount, attach the brackets to the back of your TV using the VESA holes. Follow the instructions provided with your TV mount kit for the specific bracket installation.
  6. Mount the TV: With the help of another person, carefully lift the TV and hook the brackets onto the wall plate. Ensure the brackets engage securely with the wall plate.
  7. Test the mount: Gently try to wiggle the TV to ensure it's securely mounted. Verify that it's level and adjust if necessary. Double-check that all screws and bolts are tightened properly.
  8. Conceal the cables: To create a clean and organized look, consider concealing the cables. You can use cable management solutions such as cable raceways or in-wall cable routing kits to hide the cables running from the TV to your devices.

Congratulations! You have successfully installed a TV mount on a concrete wall. Remember to follow the manufacturer's instructions provided with your specific TV mount kit for the best results.
